Ko Beijing Huade Hydraulic Industrial Group he kamupene rongonui rongonui mo te hoahoa, te hanga me te ratonga o nga reera waipēhi me nga taputapu. Ka taea e Huade® 4WE 6 J solenoid directional valve te whakakapi i te tauira ano e tukuna ana e Rexroth na te rua o te mahi tahi me Rexroth mai i te 1979. Ko te raupapa solenoid directional valve WE 6 kua paahitia te tohu CE. Ka whakapau kaha a Huade ki te kounga hei whakarite kia pai ake te mahi o ia takirere aronga. R&D me te punaha whakahaere whakaputa ka tutuki ISO9001, ISO14001, me ISO45001. Huade® hydraulic vaolo e whakamahia nuitia ana i roto i te umanga hoia me etahi atu mara i Haina na te kaha o te mahi. He waitohu motu pono i Haina.
|
Hydraulic |
|||
|
Te pehanga teitei Tauranga A,B,P (Mpa) |
tae atu ki te 35.0 |
||
|
Tauranga T (㎫) |
21(-);16(～) |
||
|
me nga tohu A me B, me whakamahi te tauranga T hei tauranga awaawa |
|||
|
Te Rerenga Max (L/min) |
80(-);60(～) |
||
|
Wai pehanga |
Hinu Kohuke, Phosphate Ester ranei |
||
|
Awhe pokey (mm2/s) |
2.8~500 |
||
|
Awhe pāmahana wē pēhanga （℃） |
-30～+80 |
||
|
Te taumata o te poke |
Te taumata teitei e whakaaetia ana mo te poke o te wai waipēhi ki te akomanga NAS 16389. |
||
|
Hiko |
|||
|
Momo ngaohiko |
DC |
AC 50/60Hz |
|
|
Ngaohiko e waatea ana (V) |
12, 24, 42, 60, 96 |
42, 110, 120, 230 |
|
|
110, 180, 205, 220 |
50/60Hz |
||
|
Te whakapau hiko (W) |
30 |
||
|
Mana pupuri (VA) |
- |
50 |
|
|
Te hiko whakakā (VA) |
- |
220 |
|
|
Te kawenga |
tonu |
||
|
Te wa whakawhiti ki IS0 6403 |
ON (ms) |
25 ki te 45 |
10 ki te 20 |
|
OTI (ms) |
10 ki te 25 |
15 ki te 40 |
|
|
Tiaki ki te DIN |
IP 65 |
||
|
Te auau whakawhiti (huringa/h) |
ki te 15000 |
tae atu ki te 7200 |
|
|
Me nga hononga hiko te kawe whakamarumaru (PE) |
|||
Āhuatanga:
▶ Tikanga solenoid actuated directional spool valve putanga mahi teitei
▶ Te titi maku DC, AC solenoids ranei me te porowhita tango
▶ Te whakakore i te ringaringa, ka taea
▶ Ka taea te huri i te solenoid coil ki te 90°
▶ Kare e tika kia whakatuwherahia te ruuma kiki i te pehanga i te wa e huri ana te porowhita
▶ Nga hononga hiko hei hononga takitahi, hononga pokapū ranei
▶ Tauira kawe ki te Din 24 340 puka A, ISO 4401 me CETOP - RP 121H
Taupānga:
Solenoid whakahaeretia nga marere aronga o te momo 4WE 6 J te whakahaere i te tiimata, te aukati me te ahunga o te wai.
Ko te tikanga ko nga maataki mana whakahaere 4WE 6 kei roto i te whare (1), kotahi, e rua nga solenoids (2), te spool mana (3), me te kotahi, e rua ranei nga puna whakahoki (4). I roto i te ahua kua whakakorehia te hikoi (3) ka mau ki te tuunga koretake, ki te tuunga tuatahi ranei ma te whakahoki mai i nga puna (4) (haunga mo nga poipoipoka). . Ko te kaha o nga solenoids (2) ka mahi ma te plunger (5) i runga i te spool mana (3) ka panaia tenei mai i tona tuunga kupapa ki te tuunga mutunga e hiahiatia ana. Ma tenei ka tuku rere-kore mai i P ki A me B ki T, P ranei ki B me A ki T.
Ina whakakorehia te hikohiko (2), ka whakahokia te porowhita whakahaere (3) ki tona tuunga kupapa ma nga puna whakahoki (4).
Ko te whakakore i te ringaringa (6), ka taea te neke o te spool mana (3) me te kore e whakakaha te solenoid.
Te hoahoa hoahoa o te raupapa WE 6 61B
