Ko te 4/2- me te 4/3-ara arataki aronga nui kua hangaia hei waahanga whakahaere tika mo te whakapuru pereti. Ka whakakorikorihia e te solenoids orite me te miro pokapū me te porowhita tango. Ko nga solenoids e whakahaerehia ana e te hikohiko mana o waho (momo WRA) ma te hikohiko mana whakauru ranei (momo WRAE). Ka taea e te mahi a 4WRA 10 EA60-2X te taurite ki a Rexroth na te rua o te mahi tahi mo te wa roa.
| Hydraulic | |||
| Momo takirere | HD-WRA | HD-WRAE | |
| Te pēhanga mahi (MPa) | Tauranga A,P,B | 31.5 | 31.5 |
| Tauranga T | 21 | 21 | |
| Rere ingoa ingoa qv i △ P=1MPa | NS6 (L/mene) | 7, 15 me 26 | |
| NS10(L/mene) | 30 me te 60 | ||
| Te taumata o te poke (μ m) | ≤20 | ||
| Hysteresis(%) | ≤5 | ||
| Hapa whakamuri (%) | ≤1 | ||
| Te tairongo whakautu(%) | ≤0.5 | ||
| Wai pehanga | Hinu kohuke, Phosphate ester ranei | ||
| Awhe pokey | 20~380 | ||
| Awhe pāmahana ambient (℃) | -20 ki te +80 | -20 ki te +50 | |
| Taumaha (kg) | NS6 | 2 | 2.2 |
| NS10 | 6.6 | 6.8 | |
| Hiko | |||
| Hiko, solenoid | |||
| Momo takirere | HD-WRA | HD-WRAE | |
| Momo ngaohiko | DC | ||
| Mana ngaohiko (V) | ±10 | ||
| Mōrahi o nāianei mō ia solenoid(A) | 2.5 | ||
| Ātete porowhita Solenoid (Ω) | Uara matao i te 20 ℃ | 2 | |
| Max. uara mahana | 3 | ||
| Te kawenga | 100% | ||
| Paemahana pōkai (℃) | ki te +150 | ||
| Tiaki takirere ki DIN40050 | IP65 | ||
| Hiko, hikohiko whakahaere | |||
| whakahaere hikohiko | HD-VT-VSPA2-1-1X/ | whakauru i roto i te takirere | |
| Ngaohiko tuku | VDC ngaohiko ingoa | 24 | |
| Te uara whakaraiti V | 21/22 | 19 | |
| Uara whakawhāiti o runga V | 35 | ||
| Te whakapau kaha o te whakakaha | Ahau max A | 1.8 | |
| Max. te kaha o te manawa A | 3 | ||
Āhuatanga:
▶ Mo te whakapuru pereti iti
▶Hangai whakakorikori i te waapa rite mo te whakahaere i te ahunga me te rōrahi o te rere
▶ Spool mana e hāngai ana ki te puna
▶ Ko nga hikohiko whakahaere whakauru, atanga A1, F1 ranei mo te momo 4WRAE
▶ Whakamahia ma te solenoids taurite me te miro pokapū me te porowhita ka taea te tango
▶ Mana hikohiko mo te momo 4WRA
Taupānga:
Kei te whakamahia te 4WRA 10 EA60-2X takirere aronga rite ki te whakahaere i te rere me te ahunga o te wai waipēhi.
Te 4WRA 10 EA60-2X vaolo proportional most consists of: Whare (1) with mounting surface Control spool (2) with compression springs (3 ),Solenoids (4) with central thread,Kōwhiringa integrated valve hikohiko (5).
HD-4WRA(E).2X/.
I te mea kua whakakorehia te hiko (4), ka mau te porowhita whakahaere (2) ki te turanga o waenganui e nga puna kōpeketanga (3).
Te whakakorikori tika o te spool mana (2) ma te whakakaha i te solenoid taurite.E.g. te whakahaere i te solenoid "b" (4). Ka nekehia te porowhita whakahaere (2) ki te taha maui kia rite ki te tohu whakauru hiko. Puka hononga P ki A me B ki T ma nga waahanga whiti-a-waha me nga ahuatanga rere whakamua. Ko te whakakore i te hiko o te solenoid (4). Ka whakahokia te spool mana(2) ki te tuunga o waenganui ma te puna kōpeketanga (3).
Te Hanganga o te Wehenga Ahurangi 4WRA -2X
HD-4WRA(E)...A-2X
Ko te tikanga, ko te mahi o tenei putanga takirere e rite ana ki tera o te takirere me nga tuunga 3 spool. Heoi, ko nga marere e 2 nga tuunga poka ka whakauruhia ki te solenoid "a". Hei utu mo te solenoid 2nd ka whakauruhia he mono (5) mo NS 6, mo NS 10 ranei he uhi(5).
Tuhipoka mo te momo 4WRA 6..-2X/...
Ko te whakaheke i te raina tank me karo. I runga i nga tikanga whakaurunga e tika ana, me whakauru he paera pehanga tuara (te pehanga tuara approx.0.2MPa).
